Spraying
12 332156E
Spraying
1. Set pump valve ON.
2. Increase pressure enough to start hydraulic motor
stroking and allow fluid to circulate for 15 seconds;
turn pressure down.
3. Turn spray gun trigger safety OFF.
4. Adjust pressure to desired setting. Begin spraying.
5. Rotate Lock Ring clockwise to set pressure.
ti7108a
ti7110c
ti5403a
ti21143a
ti7110c
ti21062a
ti20968a
