Graco 17B484 User Manual

Technical Data
332156E 17
Technical Data
GH733ES
US Metric
Sprayer
Hydraulic Pressure 2750 psi 190 bar
Hydraulic Reservoir Capacity 4.0 gallons 15.1 liters
Honda Motor 13 HP 9.7 KW
Vanguard Motor 14 HP 10.4 KW
Maximum Delivery 4.0 gpm 15.1 lpm
Maximum Pressure 4000 psi 276 bar
Maximum Tip Size
• 1 gun .065 in. 1.65 mm
• 2 guns .046 in. 1.16 mm
• 3 guns .037 in. 0.93 mm
• 4 guns .032 in. 0.81 mm
• 5 guns .029 in. 0.71 mm
• 6 guns .026 in. 0.66 mm
Fluid Inlet 1.25 in. npt(m) 3.2 cm npt(f)
Fluid Outlet (with fitting as shipped) 0.75 in. nps(f) swivel 1.9 cm npsm
Fluid Outlet Pump 1.0 in. npt(f) 2.5 cm npt(f)
Dimensions
Weight 434 lb 197 kg
Height 49 in. 124 cm
Width 28 in. 71 cm
Length 43 in. 109 cm
Sounds Levels*
Sound Pressure 91 dB(A)
Sound Power 106 dB(A)
*measured at maximum normal load conditions
Wetted Parts
Displacement Pump steel, nitralloy, tungsten, carbide, PTFE, leather,
polyethylene
Miscellaneous
Graco-Approved Hydraulic Oil
169236 5 gallons 19 liters
207428 1 gallon 3.8 liters

Graco 17B484 Specifications

General

Brand	Graco
Model	17B484
Category	Paint Sprayer
Language	English
