Operation
334641E 15
Operation
Spray Tip Installation
1. Perform Pressure Relief
Procedure, page 9.
2. Use spray tip (A) to insert
OneSeal
™
(B) into tip guard (C).
3. Insert Spray Tip.
4. Screw assembly onto gun. Tighten.
Spray
When a RAC X™ FF LP Fine Finish Low
Pressure reversible spray tip is used,
spraying pressure can be lowered. Spraying
at a lower pressure results in less overspray
and reduces spray tip wear. Adjust the
sprayer pressure to minimize overspray.
To avoid serious injury from skin injection
do not put your hand in front of the spray tip
when installing or removing the spray tip
and tip guard.
Atomized, evenly
distributed fan pattern
Tails
