Graco 17C487 Repair

Parts
334599F 17
Parts List
Ref. Part Description Qty.
201 24W617 ROD, displacement,
includes 212
1
202* 180656 BUTTON, plug 1
203 193047 NUT, packing 1
204* 176757 GLAND, female, throat 1
205* 176754 GLAND, male throat 1
206 24W619 CYLINDER, pump
includes 219, 229
1
207* 105444 BALL, sst, 0.3125 in. 1
208* 195129 GLAND, male piston 1
209* 180073 GLAND, female, piston 1
211* 15G234 GUIDE, piston 1
212 239937 VALVE, piston
(included with 201)
1
213 15C011 GUIDE, ball 1
215 246429 KIT, seat, carbide
includes 213, 217 and
218
1
216 15B611 VALVE, intake housing 1
217* 15B112 PACKING, o-ring
(0.941 in. OD)
1
218* 105445 BALL, sst, 0.5000 in. 1
219* 17V093 O-RING, PTFE 1
220* 160516 O-RING 1
221* 176755 V-PACKING, leather,
throat
2
222* 192710 V-PACKING, throat,
V-Max
TM
UHMWPE, blue
3
223* 176749 V-PACKING, leather,
piston
2
224* 192712 V-PACKING, piston,
V-Max
TM
UHMWPE, blue
3
225
Models 17C487, 17C488, 17C489, 17C721
17C231 FITTING, pump, QD,
1/4 npt
1
Model 17M992
162453 FITTING, 1/4 npt 1
229 NUTS, retaining, not sold separately
* - Also included in Kit 244194
 - Also included in Kit 246429
Ref. Part Description Qty.
