Technical Specifications
3A4476E 35
Technical Specifications
Cordless HandHeld Sprayer
U.S. Metric
Max Working Pressure 2000 psi 14 MPa, 138bar
Weight 5.25 lb 2.4 kg
Dimensions:
Length
14.0 in. 36.1 cm
Width 5 in. 12.7 cm
Height
10.5 in. 26.7 cm
Storage Temperature Range 32° to 113° F 0° to 45° C
Operating Temperature Range 40° to 90° F 4° to 32° C
Storage Humidity Range 0% to 95% relative humidity, non-condensing
Sound Pressure Level
86.0 dBa
Sound Power Level† 90.7 dBa, Uncertainty = 0.5 dBa
Vibration Level (measured in
accordance with EN 50580:2012)
Vibration total value
a
h
= 33.2 ft/s
2
Uncertainty = 0.5 m/s
2
Vibration total value
a
h
= 10.1 m/s
2
Uncertainty = 0.2 m/s
2
Charger Power Source 120 Vac, 60 Hz, 15A, 1 Ø
Battery
Voltage (DC)
20 V MAX* 2.0 Ah Li-ion
Compact Battery Pack DEWALT
Maximum tip orifice 0.016 in. 0.41mm
Pump damage will occur if fluid freezes in pump.
Damage to plastic parts may result if impact occurs in low temperature conditions.
Changes in paint viscosity at very low or very high temperatures can affect sprayer
performance.
† All readings were taken within the priming mode at the assumed operator position. Sound
power levels were tested to ISO 3741 at 3.3 feet (1m).
* Maximum initial battery voltage (measured without a workload) is 20 volts. Nominal voltage
is 18.
