Graco A Series Repair Parts

Parts
309577D 25
Part No. 245970, E-20 and E-XP1; includes items 1-7, 9-23
Part No. 245971, E-XP2; includes items 1-7, 9-22
Part No. 245972, E-30; includes items 1-22 (shown)
* These parts are also included in the Pump Repair Kits,
which may be purchased separately. Some parts in the
kit may not be used in your pump. Order the correct kit
for your pump from the table below.
† Wet-Cup Conversion Kits may be purchased sepa-
rately to convert pumps 245970, 245971, and 245972.
See page 26 for further information.
‡ This part is also available in the Intake Spring Kit
249770, which may be purchased separately.
Ref
No. Part No. Description Qty
1 240518 ROD, displacement; sst (245970) 1
240517 ROD, displacement; sst (245971) 1
246689 ROD, displacement; sst (245972) 1
2 243346 CYLINDER, pump (245970) 1
240520 CYLINDER, pump (245971) 1
245413 CYLINDER, pump (245972) 1
3* 108526 O-RING; PTFE (245970) 2
107098 O-RING; PTFE (245971) 2
108822 O-RING; PTFE (245972) 2
4 240521 SLEEVE, cylinder; sst (245970) 1
240525 SLEEVE, cylinder; sst (245971) 1
240921 SLEEVE, cylinder; sst (245972) 1
5 195892 HOUSING, valve, intake (245970) 1
193030 HOUSING, valve, intake (245971) 1
198219 HOUSING, valve, intake (245972) 1
7 239932 VALVE, piston (245970) 1
240150 VALVE, piston (245971) 1
240580 VALVE, piston (245972) 1
8*‡ 245256 SPRING, intake ball (245972 only) 1
9 239922 SEAT, intake; carbide (245970);
includes items 10 and 11
1
244199 SEAT, intake; carbide (245971);
includes items 10 and 11
1
240918 SEAT, intake; carbide (245972);
includes items 10 and 11
1
10* 107079 . O-RING; PTFE (245970) 1
108526 . O-RING; PTFE (245971) 1
107098 . O-RING; PTFE (245972) 1
11* 105445 . BALL, intake; sst; 0.5 in. (13 mm)
(245970)
1
102972 . BALL, intake; sst; 0.875 in. (22
mm) (245971)
1
107167 . BALL, intake; sst; 1 in. (25 mm)
(245972)
1
12 192624 GUIDE, ball (245970) 1
193027 GUIDE, ball (245971) 1
193391 GUIDE, ball (245972) 1
13* 117450 SEAL, u-cup, piston; UHMWPE
(245970)
1
117449 SEAL, u-cup, piston; UHMWPE
(245971)
1
117448 SEAL, u-cup, piston; UHMWPE
(245972)
1
14* 15B078 BUSHING, piston (245970) 1
15B077 BUSHING, piston (245971) 1
15B079 BUSHING, piston (245972) 1
15* 114054 O-RING; Viton® (245970) 1
106556 O-RING; Viton (245971) 1
107306 O-RING; Viton (245972) 1
16* 105444 BALL, piston; sst; 0.3125 in. (8 mm)
(245970)
1
101947 BALL, piston; sst; 0.375 in. (10 mm)
(245971)
1
107203 BALL, piston; sst; 0.5625 in. (14
mm) (245972)
1
17* 15B075 BUSHING, rod (245970) 1
15B074 BUSHING, rod (245971) 1
15B076 BUSHING, rod (245972) 1
19
† 193046 NUT, packing (245970) 1
193032 NUT, packing (245971) 1
189589 NUT, packing (245972) 1
20* 117447 SEAL, u-cup, throat; UHMWPE
(245970)
1
117446 SEAL, u-cup, throat; UHMWPE
(245971)
1
117448 SEAL, u-cup, throat; UHMWPE
(245972)
1
21* 117597 WASHER, felt (245970) 2
117599 WASHER, felt (245971) 2
117600 WASHER, felt (245972) 2
22* 551528 RING, retaining (245970) 1
117718 RING, retaining (245971) 1
117719 RING, retaining (245972) 1
23* 15B661 TOOL, installation, seal (245970
only); not shown; part of Repair Kit
246420
1
Pump Part No. Repair Kit
245970 246420
245971 246421
245972 246422
Ref
No. Part No. Description Qty
