Graco A Series Repair Parts

Technical Data
309577D 27
Technical Data
Viton® is a registered trademark of the DuPont Com-
pany.
Loctite® is a registered trademark of the Loctite Com-
pany.
Category Data
Maximum working pressure 3500 psi (24.5 MPa, 245 bar)
Effective area of displacement
246830 and 245970: 0.396 in.
2
(2.55 cm
2
)
246831 and 245971: 0.552 in.
2
(3.56 cm
2
)
246832 and 245972: 0.743 in.
2
(4.79 cm
2
)
Fluid inlet size 246830, 246831, 245970, and 245971: 3/4 npt(m)
246832 and 245972: 1 npsm(m)
Fluid outlet size 246830 and 245970: 1/4 npt(f)
246831, 246832, 245971, and 245972: 3/8 npt(f)
Wetted parts stainless steel, PTFE, zinc-plated carbon steel, acetal, tungsten carbide,
chrome plating, ultra-high molecular weight polyethylene
