Kits and Accessories
3A3995L 15
Kits and Accessories
CSP Divider Block Inlet Fittings
◆ Always connect fittings to Graco designed stud to
ensure connections.
CSP Divider Block Outlet Doubling Plug
✿ Torque to10 to12 ft.-lbs (13.56 to 16.27 N•m)
CSP Divider Block Outlet Combination Kits
NOTE: Only used for combination CSP valve outlet
numbers 1 and 2 (See F
IG. 16, page 16).
CSP Divider Block Outlet Fittings
NOTE:
Always use Graco outlet fittings for your applications.
◆ Always connect fittings to Graco designed stud to
ensure connections.
★ Torque to 12 to14 ft.-lbs (16.27 to18.98 N•m)
❖Used only for connection to nylon tube
†Used for nylon tube with outer diameter of 0.25 +/-
0.005 in.
Part No. Description Qty
17L442◆
FITTING, push to connect, 1/4 in. hose
stud x 1/8 in. npt male straight, 2000
psi (13.79 MPa, 137.9 bar)
1
17L449
◆
FITTING, push to connect,
6 mm stud x 1/8 bspt male 90°, 2000
psi (13.79 MPa, 137.9 bar)
1
17L545
◆
FITTING, push to connect,
6mm stud x 1/8 bspt male straight,
2000 psi (13.79 MPa, 137.9 bar)
1
17L546
FITTING, compression, 6 mm x 1/8
bspt male 90°, 3000 psi (20.68 MPa,
206.8 bar)
1
17L548
FITTING, compression, 6 mm x 1/8
bspt male straight, 3000 psi (20.68
MPa, 206.8 bar)
1
17T780
FITTING, compression, 6 mm x 1/8 npt
male straight, 3000 psi (20.68 MPa,
206.8 bar)
1
17T781
FITTING, compression, 6 mm x 1/8 npt
male 90°, 3000 psi (20.68 MPa, 206.8
bar)
1
Part No. Description Qty
17L651✿
PLUG, outlet doubling, 3000 psi (20.68
MPa, 206.8 bar)
1
Part No. Description Qty
25T510
KITS, combination, 6mm OD steel
tube, 3000 psi (20.7 MPa, 206.8 bar)
25T511
KITS, combination, 1/4 in. OD steel
tube, 3000 psi (20.7 MPA, 206.8 bar)
Part No. Description Qty
17Y692★❖†
FITTING, compression with check
valve, 1/4 in. tube, 1000 psi (6.9 MPa,
69 bar)
1
17L440★❖†
FITTING, push to connect, 1/4 in. OD
tube x M10 with check valve, 625 psi
(4.31 MPa, 43.1 bar)
1
17L441◆★
FITTING, push to connect, 1/4 in. hose
stud x M10 with check valve, 2000 psi
(13.79 MPa, 137.9 bar)
1
17L458◆★
FITTING, push to connect, 6 mm hose
stud x M10 with check valve, 2000 psi
(13.79 MPa, 137.9 bar)
1
17L543★❖
FITTING, push to connect, valve outlet,
6 mm OD tube, 1000 psi (6.9 MPa, 69
bar)
1
17L550★
FITTING, compression, valve outlet, 6
mm OD tube, with check valve, 3000
psi (20.68 MPa, 206.8 bar)
1
17Y693★
ADAPTER, M10 x 1/8 npt female, with
check valve, 5076 psi (35 MPa, 350
bar)
1
17Y689
Fitting, push to connect, 6 mm stud x
1/8 npt male, straight, 2000 psi (13.79
MPa, 137.9 bar)
20A080★
Fitting, compression with check valve,
valve outlet, 1/4 in. OD steel tube,
3000 psi (20.7 MPa, 206.8 bar)
1
