Graco CSP Series - Technical Specifications; California Proposition 65

Technical Specifications
3A3995L 21
Technical Specifications
*This dimension varies and is determined by the number of outlets. See No. of Outlets, page 21 for this dimension.
California Proposition 65
CSP Valve
US Metric
Type Divider valve
Model See Models, page 3
Lubricant Output (per outlet, per cycle)
0.012 in.
3
0.2 cc
Minimum Operating Pressure 350 psi 24.1 bar, 2.41 MPa
Maximum Operating Pressure 5076 psi 350 bar, 35 MPa
Inlet Connection Size 1/8 in. bspp, 1/8 in. npt
Outlet Connection Size M10 x 1 (f)
Maximum Working Temperature 212°F 100°C
No. of Outlets (L, page 21) LENGTH
6 outlets 2.4 in. 60 mm
8 outlets 3.0 in. 75 mm
10 outlets 3.5 in. 90 mm
12 outlets 4.0 in. 105 mm
14 outlets 4.5 in. 120 mm
16 outlets 5.25 in. 135 mm
18 outlets 6.0 in. 150 mm
20 outlets 6.5 in. 165 mm
22 outlets 7.0 in. 180 mm
Monitoring Cycle indicator / Limit switch / Proximity switch
Lubricant Max up to #2 NLGI grade
Material of Construction Carbon Alloy Steel
CALIFORNIA RESIDENTS
WARNING: Cancer and reproductive harm – www.P65warnings.ca.gov.
