Installation

10 332316E

Power DIN AC - 15 foot: Part No. 123358

Din Connector Specifications

• DIN 43650 Form A, 18 mm, assembled to power cable manufacturer’s instructions

• Rated to 6 Amps minimum at 250V AC

Cable Specifications

• United States/Canada: 3 conductor 16 AWG UL62 and CSA 22.2 No. 49 listed SOOW cable with black, white,

green insulation

• Europe: 3 Class-5 conductor, 1.5 mm

Agency Listed H07RN-F cable with blue, brown, green/yellow insulation

• Japan/Taiwan: 3 conductor, 1.25 mm

Agency Listed 2 PNCT cable with black, white, red insulation

• SEA/India/Australia: 3 conductor, 1.5 mm

Agency Listed H07RN-F blue, brown, green/yellow insulation

• China: 3 conductor, 1.5 mm

Agency Listed YZW cable with blue, brown, green/yellow insulation

Pin and Related Wire Color (F

IG. 3, page 11)

UnitedStates/

Canada

Europe Japan/Taiwan

SEA/India/

Australia

China

1 LINE Black Brown Black Brown Brown

2 NEUTRAL White Blue White Blue Blue

3NotUsed NotUsed NotUsed NotUsed NotUsed NotUsed

4 GROUND Green Green/Yellow Red Green/Yellow Green/Yellow

Colo r

Pin PinName
