Graco G1 User Manual

Installation
332316E 9
Wiring and Installation Diagrams
NOTE: Graco does not provide a power cable with the G1. Power cables are available for purchase from Graco or the
user may provide their own. See Table 1 for reference pages containing additional information related to Graco power
cables.
Table 1: Graco Power Cables
Cable Part No. Diagram Symbol Page #
123358
DIN 15 ft.
Power DIN AC 10
Power DIN DC 12
127783
CPC 15 ft., 3-wire
Power CPC DC 14
124333
5 meter
female to male
M12 Eurofast
Low Level Outputs
16
124300
5 meter
female M12 Eurofast
16
124594
4-pin
Eurofast Field-wireable
17
124595
5-pin female
Eurofast Field-wireable
17
