Graco G40 User Manual

Technical Data
333182A 11
Technical Data
*All readings were taken with fan valve fully closed, (full fan size) at 20 psi (140 kPa, 1.4 bar) and 100 psi (0.7 kPa, 7
bar) and at the assumed operator position. Sound Power tested to ISO 9614-2.
G40 Air Assisted Airless Spray Gun
US Metric
Maximum Working Fluid Pressure 4 000 psi 28 MPa, 280 bars
Maximum Working Air Pressure 100 psi 0,7 MPa, 7 bars
Maximum Working Fluid Temperature 110°F 43°C
Fluid inlet 1/4–18 npsm
Air Inlet 1/4-18 npsm
Gun Weight 16 oz 450 grams
Sound Pressure*: 20 psi (140 kPa, 1.4 bar) 66.9 dB(A)
Sound Pressure*: 100 psi (0.7 kPa, 7 bar) 80.0 dB(A)
Sound Power*: 20 psi (140 kPa, 1.4 bar) 76.8 dB(A)
Sound Power*: 100 psi (0.7 kPa, 7 bar) 89.9 dB(A)
Wetted Parts Stainless Steel, Carbide, Ultra High Molecular Weight
Polyethylene, Acetal, PTFE, Nylon, Flouroelastomer

Graco G40 Specifications

General

Maximum Fluid Pressure	3000 psi
Gun Weight	20.8 oz
Air Inlet Size	1/4 npsm(m)
Fluid Inlet Size	1/4 in npsm
Fluid Delivery	0.3 gallons per minute
Wetted Parts	Stainless Steel
Type	Air-Assisted
Power Source	Pneumatic
