Graco GH 833 - Securing Unit to Vehicle Bed

Removing Handle
311283J 31
Securing Unit to Vehicle Bed
For fixed mounting, fasten U-bolts over sprayer frame
as indicated in the following illustration.
1. Reposition handle, steps 1-5, page 30.
2. Place U-bolts over sprayer frame and through holes
in vehicle bed. Place a washer and nut over bolt
end. Using a wrench, tighten nut securely.
67
79
78
80
21
10
86
46
45
5
81
82
5a
19
4
6
65
24
14
86
87
139
ti20932a
