19
308-644
AVAILABLE TIPS
Switch Tip use only in the RAC IV Dripless Guard and Performance Series RAC Dripless Guard.
Orifice
Size
Flow Rate* Fan Width** Inch (mm)
Inch gpm (lpm) 2.0–4.0
(51–102)
4.0–6.0
(102–152)
6.0–8.0
(152–203)
8.0–10.0
(203–254)
10.0–12.0
(254–305)
12.0–14.0
(305–356)
14.0–16.0
(356–406)
16.0–18.0
(406–457)
18.0–20.0
(457–508)
0.007 .053 (.20) 221–207 221–307
0.009 .087 (.33) 221–209 221–309 221–409 221–509 221–609
0.011 .13 (.49) 221–111 221–211 221–311 221–411 221–511 221–611
0.013 .18 (.69) 221–203 221–213 221–313 221–413 221–513 221–613
0.015 .24 (.91) 221–115 221–215 221–315 221–415 221–515 221–615 221–815
0.017 .31 (1.17) 221–217 221–317 221–417 221–517 221–617 221–817 221–917
0.019 .39 (1.47) 221–201 221–219 221–319 221–419 221–519 221–619 221–819
0.021 .47 (1.79) 221–221 221–321 221–421 221–521 221–621 221–721 221–821
0.023 .57 (2.15) 221–223 221–323 221–423 221–523 221–623 221–723
0.025 .67 (2.54) 221–225 221–325 221–425 221–525 221–625 221–725
0.027 .78 (2.96) 221–327 221–427 221–527 221–627 221–827
0.029 .90 (3.42) 221–429 221–529 221–629 221–729
0.031 1.03 (3.90) 221–331 221–431 221–531 221–631 221–831
0.033 1.17 (4.42) 221–433 221–533 221–633 221–833
0.035 1.31 (4.96) 221–235 221–435 221–535 221–635 221–735 221–835 221–935
0.037 1.47 (5.56)
0.039 1.63 (6.18) 221–439
0.041 1.80 (6.83)
0.043 1.99 (7.51) 221–443 221–543
0.045 2.17 (8.23) 221–645
0.047 2.37 (8.98)
0.049 2.58 (9.75)
0.051 2.79 (10.57) 221–451 221–551
0.053 3.01 (11.41)
0.055 3.21 (12.29) 221–455 221–555 221–655
0.057 3.49 (13.2)
0.059 3.74 (14.14)
0.061 3.99 (15.12)
0.063 4.26 (16.13) 221–563
0.065 4.53 (17.17) 221–665
Note:
* Flow rate established with water at 2000 psi (138 bar) at the tip.
** Pattern length (Fan Width) established by spraying the solvent base enamel with viscosity set at 20 seconds. Zahn #4 and pressure set at 1600
psi (110 bar) at the tip. The distance between the tip and the target surface is 12.0 inch (305 mm).
