Operation
8 3A0101F
Cutting Material
1. Start Engine, see page 7.
2. Connect Emergency Shut-Off Cord (C) to operator.
3. Disengage Rear Wheel Brake (G).
4. Slide Engine Throttle Lever (A) to desired setting.
NOTE: Drum clutch will not engage when engine is
running at idle. 480/630 Models: LineDriver must
be attached to GrindLazer.
5. Push down on handle bars, pull engagement lever,
and lower drum into DOWN position.
6. Rotate Drum Adjustment Dial (D) until drum comes
into contact with surface and desired depth is
reached.
NOTE: Several test cuts may be needed to dial-in
desired cutting depth.
NOTE: On harder surfaces, it may be best to make
several passes in increments of 1/32 in. to get to the
desired depth.
ti14762a
ti14757a
ti6483a
ti14755a
ti14756a
