Technical Data
3A2797R 97
Technical Data
HFR for NVH Foam
US Metric
Maximum fluid working pressure 2000 psi 14 MPa, 138 bar
Maximum Fluid Temperature 180°F 82°C
Fluid Inlet Feed Pressure Range 50 psi to 100 psi 345 kPa, 3.4 bar to
0.7 MPa, 7 bar
Fluid Inlet:
Component A (Red)
1/2 npt(f)
Fluid Inlet:
Component B (Blue)
3/4 npt(f)
Fluid Outlet:
Component A (Red)
#8 (1/2 in.) JIC (3/4-16 unf), with #5 (5/16 in.) JIC adapter
Fluid Outlet:
Component B (Blue)
#10 (5/8 in.) JIC (7/8-14 unf), with #6 (3/8 in.) JIC adapter
Fluid Circulation Ports 1/4 npsm(m), with plastic tubing, 250 psi (1.75 MPa, 17.5 bar) maximum
Line Voltage Requirement:
230V / 3 phase Models
195-264V, 50/60 Hz
Line Voltage Requirement:
400V / 3 phase Models
360-440V, 50/60 Hz
See 400 V Power Requirements on page 5
Amperage Requirement See Models on page 4
Sound Power 93 dB
Heater Power
(A (Red) and B (Blue) heaters total, no hose)
10 kW full load
(12 kW for 1:1 Models Only)
Hydraulic reservoir capacity 9 gal. (34 liters)
Recommended hydraulic fluid Citgo A/W Hydraulic Oil, ISO Grade 46
Weight:
Units with 10 kW Heaters
868 lb (394 kg)
Wetted Part Aluminum, stainless steel, zinc-plated carbon steel, brass, carbide,
chrome, fluoroelastomer, PTFE, ultra-high molecular weight polyethylene,
chemically resistant o-rings
All other brand names or marks are used for identification purposes and are trademarks of their respective owners.
