Technical Data
22 3A3392B Operation
Technical Data
Wetted parts...PTFE, Nylon, polyurethane, V-Max™
leather, tungsten carbide, stainless steel, chrome plat-
ing, nickel-plated carbon steel, ceramic
LineLazer 130
HS
Engine Honda GX120cc
US Metric
Maximum fluid working pressure 3300 psi (227 bar, 22.7 MPa)
Maximum free-flow delivery 1.3 gpm 4.9 lpm
Cycles per gallon/liter 85 cpg 22.5 cpl
Hydraulic reservoir capacity 1.25 gallons (4.73 liters)
Hydraulic pressure 1825 psi (124 bar)
Maximum Tip Size
1 gun 0.037 in.
2 guns 0.029 in.
Noise level (dBa)
Sound power
110 dBa per ISO 3744
Sound pressure
96 dBa measured at 3.1 feet (1m)
Vibration level*
Left Hand
2.90 m/sec
2
Right Hand
2.83 m/sec
2
* Vibration measured per ISO 5349 bsed on 8 hr daily exposure
Inlet/Outlet Sizes
Inlet paint strainer
16 mesh (1190 micron) stainless steel screen, reusable
Outlet paint filter
50 mesh (250 micron) stainless steel screen, reusable
Pump inlet size 1 in. npsm(m)
Fluid outlet size 3/8 npt(f)
Dimensions/Weight
Height 44.5 in. 113.03 cm
Length 68.25 in. 173.36 cm
Width 34.25 in. 87.0 cm
Weight (dry, without packaging) 263 lb 119 kg
