Graco LineLazer V250SPS Manual

Steering Cable Replacement
4 3A6981C Repair
Steering Cable Replacement
Removal
NOTE: Both cables must always be replaced, even if
only one failed. Repeat steps 5-7 for each cable.
1. Perform Pressure Relief Procedure, page 3.
2. Loosen four screws and remove pad.
3. Remove six screws and control shroud.
ti23930a
ti23931a
