Start Up
3A4416A 15
11. When sprayer starts pumping, flushing
fluid and air will be purged from the
sprayer. Allow fluid to flow out of drain
tube, into waste pail, for 30 to 60 sec-
onds.
12. Turn ON/OFF switch to OFF position.
If flushing fluid fails to come out of the drain
tube, perform the steps below until flushing
fluid flows up the suction tube and out the
drain tube.
1. Some fluids prime faster if the ON/OFF
switch is toggled on and off so the pump
can slow and stop. Turn ON/OFF switch
ON for three seconds, then OFF until
motor stops, then ON again for three
seconds, then OFF until motor stops.
Continue until sprayer is primed. If
flushing fluid does not flow up suction
tube, see next step.
2. Remove suction tube. Insert pointed
end of a pencil into the inlet and push
up to free inlet valve ball.
Install suction tube and repeat Flush
Storage Fluid, page 14.
