Maintenance
34 3A4416A
4. Slide pump assembly off the mounting
pins.
ProXChange Removal Tool
An integrated tool is included in the frame to
remove the ProXChange packing assembly.
See Pump repair manual for complete repair
instructions.
5. Clean any debris and dried paint from
the cavity and replace the ball and
spring. Tighten inlet valve to pump
using integrated tool on the frame.
Pump Installation
1. Slide pump assembly onto the mounting
pins.
a. Move pump rod up or down until cap
is level with the opening in the yoke.
b. Push on pump rod to slide pump
assembly back on to mounting pins.
ti26930a
ti27036a
ti27037a
