Graco Merkur User Manual

Models
8 3A7004B
PERSONAL PROTECTIVE EQUIPMENT
Wear appropriate protective equipment when in the work area to help prevent serious injury, including
eye injury, hearing loss, inhalation of toxic fumes, and burns. Protective equipment includes but is not
limited to:
• Protective eyewear, and hearing protection.
• Respirators, protective clothing, and gloves as recommended by the fluid and solvent manufacturer.
SPECIFIC CONDITIONS OF SAFE USE
Equipment must comply with the following conditions to avoid a hazardous condition which can cause
fire or explosion.
• All labels and identification plates must be cleaned with a damp cloth (or equivalent).
• The electronic monitoring system is required to be grounded. See Grounding instructions.
WARNING

Graco Merkur Specifications

General

Fluid Delivery	Up to 4.0 gpm (15.1 lpm)
Air Inlet Size	1/4 in npsm
Fluid Inlet Size	1/2 in npsm
Fluid Outlet Size	1/4 in npsm
Maximum Air Input Pressure	100 psi (0.7 mpa)
Maximum Fluid Pressure	up to 3300 psi (22.7 mpa)
Pump Type	Air-Operated Piston Pump
Flow Rate	up to 4.0 gpm (15.1 lpm)
Power	Air operated
Inlet/Outlet Size	Fluid Inlet: 1/2 in npsm, Fluid Outlet: 1/4 in npsm
