Troubleshooting
311238G 15
FIG. 6. Cutaway View, Standard and DataTrak Models
TI8624a
Poppet
Poppet Piston Shaft SealsPiston O-ring
Air Valve
Seals
Air Valve
Spool
Air Valve
Slide Plate
Air Valve
Seals
F
IG. 7. Cutaway View, Models with Linear Sensor
TI8066b
Poppet
Poppet Piston Shaft SealsPiston O-ring
Air Valve
Seals
Air Valve
Spool
Air Valve
Slide Plate
Air Valve
Seals
Linear Sensor
