Parts
26 311238G
NXT Model 2200 Air Motors
The parts listed below are common to all NXT Model 2200 Air Motors. Parts which vary by air motor are found in the
table at the bottom of this page.
▲ Replacement Danger and Warning labels, tags, and cards are available at no cost.
* Parts included in Repair Kit NXT200 (purchase separately).
★ Parts included in Low Noise Exhaust Conversion Kit NXT111 (purchase separately).
Ref.
No. Part No. Description Qty
2 NXT204 CYLINDER 1
3 NXT202 COVER, bottom 1
4 NXT201 PISTON ASSEMBLY; includes item 10 1
7* 161562 PACKING, V-block; nitrile 1
8* 15H610 PACKING, backup; leather 2
9* 15F453 RING, retaining 1
10 NXT106 BUMPER, piston; includes magnet 1
12 NXT100 POPPET; includes items 12a-12d 2
12a
NXT101
. O-RING; buna-N 1
12b . O-RING; buna-N 1
12c . O-RING, backup; buna-N 1
12d . O-RING; buna-N 1
13 119050 BOLT, hex hd; 1/2-13 x 8 in. (203 mm) 4
14 15F639 NUT, with lockwasher; 1/2-13 4
15 NXT203 MUFFLER 1
17* 15F458 O-RING, piston; nitrile 1
18* 15F449 O-RING, end cap; nitrile 2
20★ 119990 O-RING; buna-N 1
21 15F931 RING, lift 1
41 120088 SCREW; 3/8-16 x 4 in. (101 mm) 4
43 120091 SCREW, thread forming; 1/4-20 x 2 in.
(51 mm)
4
44 120092 SCREW, thread forming; 1/4-20 x 2-1/2
in. (63 mm)
2
46* 253476 GASKET 1
47 287844 COVER, valve, outer 1
51▲ 15F674 LABEL, safety 1
52▲ 15F973 LABEL, safety 1
58 120206 MUFFLER, poppet 2
59 277366 BUMPER 1
60 116343 SCREW, ground; M5 x 0.8 1
61 111307 WASHER, lock; 5 mm 1
62 NXT112 KNOB, de-ice 1
Ref.
No. Part No. Description Qty
Ref.
No. Description
Air Motor Part Numbers
QtyN22DN0 N22DT0 N22DH0 N22LN0 N22LT0 N22LH0 N22RN0 N22RT0 N22RH0
1 CAP, top 15F473 15F473 15F955 15F473 15F473 15F955 15F473 15F473 15F955 1
22 KIT, de-ice exhaust,
includes items 20, 25, 44,
56, 57
NXT110 NXT110 NXT110 1
23 KIT, remote exhaust;
includes items 20, 44
NXT105 NXT105 NXT105 1
24 KIT, low noise exhaust;
includes items 20, 22, 25,
44, 54, 55, 56, 57, 63
NXT104 NXT104 NXT104 1
25 SCREW, machine, hex
hd; 1/4-20 x 1 in. (25 mm)
120730 120730 120730 120730 120730 120730
2
30 COVER, top 15G377 15G576 15G379 15G377 15G576 15G379 15G377 15G576 15G379 1
33 ADAPTER, lift ring
15F772 15F772 15F772 1
35 SENSOR ASSEMBLY 287839 287839 287839 1
36 GUIDE, strain relief
120143 120143 120143 1
40 AIR VALVE ASSEMBLY;
see page 35
NXT107 NXT108 NXT109 NXT107 NXT108 NXT109 NXT107 NXT108 NXT109 1
45 SCREW, thread-forming;
1/4-20 x 1/2 in. (13 mm)
107257
107257 107257 1
107257 107257 107257 3
107257 107257 107257 4
54★ DEFLECTOR 15H179 15H179 15H179 1
55★ SCREW, thread-forming;
4-40 x 3/8 in. (10 mm)
112546 112546 112546 2
56 SEAL, exhaust 15H190 15H190 15H190 15H190 15H190 15H190 1
57★ O-RING; buna-N 111151 111151 111151 111151 111151 111151 1
63★ DIFFUSER, exhaust 15G689 15G689 15G689 1
