Graco PR70 - Kit 17 J520 Parts

Kit 17J520 Parts
3A3229B 3
Kit 17J520 Parts
* Not Shown.
FIG. 1: Parts in Valve Upgrade Kit 17J520
1
8
4
6
2
7
2
Ref Part Description Quantity
1 17D916 BRACKET, shelf 1
2 128266 SCREW, cap, socket head, 4-40 4
4 128538 CABLE, gca, pr70 1
5 61/2906-BK/11* HOSE, .245 id x .375 od, pu, 95 dur 2 ft
6 C27076 NUT 4
7 128170 SCREW, hex, head, m4 x .7 x 10 mm 2
8 17K155 VALVE, solenoid, 3 way 1
