Graco Reactor 2 E-30 User Manual

Troubleshootin
g
Error Location Type Description
Cause Solution
T6DH Hose
Sensor Error
Hose
Disconnected
or shorted RTD
cable in hose or
bad FTS.
Expose each hose RTD connection
to check and retighten any loose
connector. Measure hose RTD
cable and FTS continuity. See
Repair Heated Hose, page 71.
Order RTD Test kit 24N365 for
measurement.
Disconnect the hose RTD and
use Hose Manual Mode or Hose
Resistance Mode to continue the
job until repair can be completed.
Hose Resistance Mode requires a
saved calibration factor. Refer to
your proportioner operation manual
to enable Hose Control Modes.
Shorted RTD
cable in hose or
FTS.
Expose eac
h hose RTD connection
to check f
or exposed and shorted
RTD wires
. Measure hose RTD
cable and
FTS continuity. See
Repair He
ated Hose, page 71.
Order RTD
Test kit 24N365 for
measure
ment.
Disconn
ect the hose RTD and
use Hose
Manual Mode or Hose
Resist
ance Mode to continue the
job unt
il repair can be completed.
Hose Re
sistance Mode requires a
saved c
alibration factor. Refer to
your pr
oportioner operation manual
to ena
ble Hose Control Modes.
T6DT
TCM
Sensor Error
TCM
Shorted A or B
Heater RTD
If the error still occurs with the hose
FTS unplugged, one of the heater
RTDs is bad. Unplug the A or B
RTD from the TCM. If unplugging an
RTD fixes the T6DT error, replace
the RTD.
333024N 37
