Graco Reactor 2 E-30 User Manual

Parts
25P388
Ref
Part Description
Qty.
801 18A877
HOUSING, high pressure meter
1
802
25C298 GEAR, magnets, sd/matrix
1
803 15V690
GEAR, oval, metering element
1
804 166623
PACKING, o-ring
1
805 192387 PIN, dowel 2
806 109114
SCREW, cap, sch
8
807 18A878
CAP, high pressure meter
1
808 25E134
BOARD, assy reactor ratio monitor
1
809 110163
SCREW, thd forming, pnh
2
810 18A879
COVER, high pressure meter
1
25E486PKG FITTING, swivel, JIC-08, 3/4–16 orb
1
811
25E474PKG FITTING ,swivel, JIC, 10X3/4-16 orb
1
117502
FITTING, reducer, #5 x #8 (JIC)
1812
117677
FITTING, reducer, #6 X #10 (JIC)
1
813 113360 LABEL, blank 1
814 070268
LUBRICANT, grease
1
17Y236
FITTING, 45 deg elbow, 3/4 x 3/4
1815
17Y235
FITTING, 45 deg elbow, 3/4 X 7/8
1
816 18A979
LABEL, branding, G-3500
1
817 112310
SCREW, cap, sch
4
818 120853 PIN, dowel 2
▲
Replace
ment Warning labels, signs, tags, and cards are available at no cost.
96 333024N
