Technical Data
311512A 47
Technical Data
*Full load amps with all devices operating at maximum capabilities with 210 ft (64.1 m) of hose.
**When a surge transient is applied to the power lines of the unit, heat to the hose may be interrupted and require the
hose heat switch to be manually cycled.
Category Data
Maximum Fluid Working Pressure 2000 psi (1.4 MPa, 140 bar)
Maximum Air Working Pressure 120 psi (0.84 MPa, 8.4 bar)
Machine Maximum Power with hose 9000 Watts
Voltage Requirement (50/60 Hz)
(230 V Nominal: 195-253 VAC)
(380 V Nominal: 338-457 VAC)
230 V, 1 Phase
230 V, 3 Phase (Delta)
380 V, 3 Phase (WYE 220 V Nominal to Neutral)
Amperage Requirement (Full Load Peak)* 40 amps @ 230 V, 1 Phase
32 amps @ 230 V, 3 Phase
18.5 amps @ 380 V, 3 Phase
Maximum Heater Fluid Temperature 190 °F (88 °C)
Maximum Hose Fluid Temperature 180 °F (82 °C)
Maximum Ambient Temperature 120 °F (49 °C)
Maximum Output 20 lb/min. (9.0 kg/min.)
Output Per Cycle (A and B) 0.028 gal/cycle (0.105 ltr/cycle)
Overpressure Relief Shutdown 2250 psi (15.5 MPa, 155 bar)
Over Temperature Shutdown (Primary Heater) 230 °F (110 °C)
Heater Power 6000 Watts
Hose Power 2790 Watts
Sound Pressure 86.3 dB(A) at 2000 psi (14 MPa, 140 bar), 0.5 gpm (1.9 lpm)
Sound Power, per ISO 9614-2 91.6 dB(A) at 2000 psi (14 MPa, 140 bar), 0.5 gpm (1.9 lpm)
Viscosity Range 250-1500 centipoise
Maximum Fluid Inlet Pressure 400 psi (2.7 MPa, 27 bar)
Fluid Inlet/Strainer Filter 20 mesh standard (optional - 60/40 mesh)
Air inlet Filter Mesh 5 Micron
Component B (Resin) Inlet 3/4 npt(f) swivel
Component A (Isocyanate) Inlet 1/2 npt(f) swivel
Recirculation/Block Hose Connections Iso (A) side: #5 JIC (m); Resin (B) side: #6 JIC (m)
Maximum Heated Hose Length 310 ft. (95 m) 210 ft of 3/8 ID @ 12 watts/ft, 310 ft @ 9 watts/ft
Height 39.5 in. (1003.3 cm)
Width 27.2 in. (690.9 cm)
Depth 25.0 in. (635 cm)
Weight 250 lb (117.6 kg)
Wetted Parts Carbon steel, stainless steel, chrome, aluminum,
Fluoroelastomer, PTFE, nylon
Certification CE **
