Graco Reactor A-25 Operation

Setup
309812D 17
See T
ABLE 1. Does not include air compressor
or hydraulic power supply.
* Full load amps with all devices operating at maximum
capabilities. Fuse requirements at various flow rates and
mix chamber sizes may be less.
** Total system watts for all units, using 310 ft (94.6 m)
hose.
2. Electrical requirements
WARNING
Installing this equipment requires access to parts
which may cause electric shock or other serious injury
if work is not performed properly. Have a qualified
electrician connect power and ground to main power
switch terminals, see page 18. Be sure your installa-
tion complies with all National, State and Local safety
and fire codes.
Table 1: Electrical Requirements
(kW/Full Load Amps)
A SERIES
Part
No. Model
Voltage
(phase)
Full
Load
Peak
Amps*
System
Watts**
246037 A-25 230V (1) 62 14,540
246750 A-25 230V (3) 40 14,540
246751 A-25 380V (3) 22 14,540
246038 A-50 230V (1) 84 19,640
246754 A-50 230V (3) 57 19,640
246755 A-50 380V (3) 33 19,640
A-XP SERIES
246639 A-XP2 230V (1) 62 14,540
246752 A-XP2 230V (3) 40 14,540
246753 A-XP2 380V (3) 22 14,540
248635 A-XP2
2:1
230V (1) 62 14,540
248636 A-XP2
2:1
230V (3) 40 14,540
248637 A-XP2
2:1
380V (3) 22 14,540
H SERIES
246039 H-50 230V (1) 84 19,640
246756 H-50 230V (3) 57 19,640
246757 H-50 380V (3) 33 19,640
H-XP SERIES
246040 H-XP3 230V (1) 84 19,640
246758 H-XP3 230V (3) 57 19,640
246759 H-XP3 380V (3) 33 19,640
HT SERIES (Heat Package Only)
246365 HT-6.0 230V (1) 44 10,340
246760 HT-6.0 230V (3) 27 10,340
246761 HT-6.0 380V (3) 18 10,340
246607 HT-10.2 230V (1) 62 14,540
246762 HT-10.2 230V (3) 40 14,540
246763 HT-10.2 380V (3) 22 14,540
246364 HT-15.3 230V (1) 84 19,640
246764 HT-15.3 230V (3) 57 19,640
246765 HT-15.3 380V (3) 33 19,640
Table 1: Electrical Requirements
(kW/Full Load Amps)
A SERIES
Part
No. Model
Voltage
(phase)
Full
Load
Peak
Amps*
System
Watts**
