Graco Reactor A-25 Operation

Technical Data
40 309812D
Technical Data
Category Data
Maximum Fluid Working
Pressure
Model A-25: 1920 psi (13 MPa, 130 bar)
Models A-50 and H-50: 2000 psi (14 MPa, 140 bar)
Models A-XP2 2:1: 2000 psi (14 MPa, 140 bar)
Models A-XP2 and H-XP3: 3000 psi (20.7 MPa, 207 bar)
Maximum Input Pressure
to Motor
Models A-25, A-XP2, and A-XP2 2:1: 120 psi (0.82 MPa, 8.2 bar) air
Model A-50: 75 psi (0.5 MPa, 5 bar) air
Models H-50 and H-XP3: 1200 psi (8.4 MPa, 84 bar) oil
Pressure Ratio
Fluid:Air Model A-25: 16:1
Model A-XP2 2:1: 17.1:1
Model A-XP2: 25:1
Model A-50: 26:1
Fluid:Oil Model H-50: 1.65:1
Model H-XP3: 2.76:1
Air Inlet Models A-25, A-XP2, and A-XP2 2:1: 1/2 npsm(f)
Model A-50: 3/4 npsm(f)
Recommended Air Sup-
ply Hose Size
Models A-25, A-XP2, and A-XP2 2:1: 1/2 in. (13 mm) ID minimum
Model A-50: 3/4 in. (19 mm) ID minimum
Air Consumption Model A-25: 40 scfm at 120 psi (0.82 MPa, 8.2 bar), 1.6 gpm (6.1 lpm)
Model A-XP2: 40 scfm at 120 psi (0.82 MPa, 8.2 bar), 1.0 gpm (3.8 lpm)
Model A-XP2 2:1: 40 scfm at 120 psi (0.82 MPa, 8.2 bar), 1.5 gpm (5.7 lpm)
Model A-50: 80 scfm at 75 psi (0.5 MPa, 5 bar), 5.0 gpm (19 lpm);
35 scfm at 75 psi (0.5 MPa, 5 bar), 2.0 gpm (7.6 lpm)
Hydraulic Supply Inlet Models H-50 and H-XP3: 3/4 npt(f)
Hydraulic Return Outlet Models H-50 and H-XP3: 1 in. npt(f)
Recommended Hydrau-
lic Hose Size
Supply Hose: 3/4 in. (19 mm) ID minimum
Return Hose: 1 in. (25 mm) ID minimum
Maximum Hydraulic Oil
Flow
Models H-50 and H-XP3: 10 gpm (3.8 lpm), 50 cycles/min
Hydraulic Oil Consump-
tion
Models H-50 and H-XP3: 1.0 gpm (38 lpm) per 5 cycles
