Typical Installation, with circulation
12 312065V
Typical Installation, with circulation
B
A
J
F
C*
P
E
D
K
K
L
J
G
R
R
* Shown exposed for clarity. Wrap with tape during operation,
TI10976a
Key
A Reactor Proportioner
B Heated Hose
C Fluid Temperature Sensor (FTS)
D Heated Whip Hose
E Fusion Spray Gun
F Gun Air Supply Hose
G Feed Pump Air Supply Lines
J Fluid Supply Lines
K Feed Pumps
L Agitator
M Desiccant Dryer
P Gun Fluid Manifold (part of gun)
R Circulation Lines
FIG. 1: Typical Installation, with circulation
