Graco Reactor E-30 Series

Technical Specifications
312065V 39
Technical Specifications
Electric Reactor Proportioning System
US Metric
Maximum Fluid Temperature 190°F 88°C
Amperage Requirement See Table 1, page 19.
Fluid Inlets 3/4 npt(f), with 3/4 npsm(f) union
Fluid Circulation Ports
1/4 npsm(m), with plastic tubing; 250 psi (1.75 MPa, 17.5
bar) maximum
Wetted Parts
Aluminum, stainless steel, zinc plated, carbon steel, brass,
carbide, chrome, chemically resistant o-rings, PTFE,
ultra-high molecular weight polyethylene
Maximum fluid working pressure
Models E-20 and E-30 2000 psi 14 MPa, 140 bar
Model E-XP1 2500 psi 17.2 MPa, 172 bar
Model E-XP2 3500 psi 24.1 MPa, 241 bar
Maximum output
Model E-20 20 lb/min 9 kg/min
Model E-30 30 lb/min 13.5 kg/min
Model E-XP1 1 gpm 3.8 liter/min
Model E-XP2 2 gpm 7.6 liter/min
Output per cycle (A and B)
Model E-20 and E-XP1 0.0104 gal 0.0395 liter
Model E-30 0.0272 gal 0.1034 liter
Model E-XP2 0.0203 gal 0.0771 liter
Heater Power
Model E-20 6000 watts
Model E-30 and E-XP1 10200 watts
Models E-XP2 and E-30 with 15.3kW of heat 15300 watts
Sound Power, per ISO 9614-2
Model E-20 80 dB(A) at 2000 psi (14 MPa, 140 bar), 0.5 gpm (1.9 lpm)
Model E-30 93.5 dB(A) at 1000 psi (7 MPa, 70 bar), 3.0 gpm (11.4 lpm)
Model E-XP1 80 dB(A) at 2000 psi (14 MPa, 140 bar), 0.5 gpm (1.9 lpm)
Model E-XP2 83.5 dB(A) at 3000 psi (21 MPa, 210 bar), 1.0 gpm (3.8 lpm)
Sound Pressure, 1 m from equipment
Model E-20 70.2 dB(A) at 2000 psi (14 MPa, 140 bar), 0.5 gpm (1.9 lpm)
Model E-30 83.6 dB(A) at 1000 psi (7 MPa, 70 bar), 3.0 gpm (11.4 lpm)
Model E-XP1 70.2 dB(A) at 2000 psi (14 MPa, 140 bar), 0.5 gpm (1.9 lpm)
Model E-XP2 73.6 dB(A) at 3000 psi (21 MPa, 210 bar), 1.0 gpm (3.8 lpm)
Fluid Outlets
Component A (ISO) #8 (1/2 in.) JIC, with #5 (5/16 in.) JIC adapter
Component B (RES) #10 (5/8 in.) JIC, with #6 (3/8 in.) JIC adapter
Weight
Model E-20 and E-XP1 342 lb 155 kg
Model E-30 400 lb 181kg
Models E-XP2 and E-30 with 15.3kW of heat: 438 lb 198 kg
