Graco Reactor E-30 Series

Parts
58 312066ZAD
51▲ LABEL, warning 198278 198278 198278 198278 198278 198278 1
52 CABLE,harness,
filter
15B385 15B385 15B385 15B385 15B385 15B385 1
65 KIT, fluid inlet 234366 234366 234367 234366 234366 234366 234367 234366 234366 234366 234367 234366 1
65a ELBOW, swivel;
3/4 npt(m) x 1”
npt(f)
160327 160327 118463 160327 160327 160327 118463 160327 160327 160327 118463 160327 2
71 SCREW,
machine
--- --- --- --- --- --- 2
72
◆
BRACKET,
heater
247523 247523 247523 247523 247523 247523 247523 247523 247523 2
BRACKET,
heater
247523 247523 247523 4
73 WASHER, lock
103181 103181 103181 103181 103181 103181 2
76 CAPACITOR 244733 244733 244733 244733 244733 244733 1
77 BRACKET
197999 197999 197999 197999 197999 197999 1
86 CABLE, over-
temperature,
jumper
15H187 15H187 15H187 15H187 15H187 15H187 15H187 15H187 15H187
1
95
◆
BOLT; hex hd;
3/8-16
100469 100469 100469 100469 100469 100469 100469 100469 100469 2
BOLT; hex hd;
3/8-16
100469 100469 100469 4
96
◆
LOCKWASHER;
3/8
100133 100133 100133 100133 100133 100133 100133 100133 100133 2
LOCKWASHER;
3/8
100133 100133 100133 4
97
◆
NUT, channel
118446 118446 118446
118446 118446 118446 118446 118446 118446 2
NUT, channel
118446 118446 118446 4
102 STRAP, motor 15B107 15B107 15B108 15B108 15B107 15B107 15B108 15B108 15B107 15B107 15B108 15B108 1
121 LABEL
15M504 15M500 15M499 15M501 15M504 15M500 15M499 15M501 15M504 15M500 15M499 15M501
1
122 INSULATOR
167002 167002 167002
167002
(qty: 4)
167002 167002 167002
167002
(qty: 4)
167002 167002 167002
167002
(qty: 4)
2
Ref. Description
Reactor Models
Qty
259024
E-XP1
259025
E-20
259026
E-30
259028
E-XP2
259029
E-XP1
259030
E-20
259031
E-30
259032
E-XP2
259033
E-XP1
259034
E-20
259035
E-30
259036
E-XP2
