Graco Reactor E-30 Series

Parts
72 312066ZAD
Circuit Breaker Modules Parts List
--- Not for sale.
✓ For models seriesA-E.
✿ For models series F.
Ref. Description
Breaker Modules
Qty
E-20 and EXP-1 Models E-30 and EXP-2 Models
A
230V,
3 phase
B
400V,
3 phase
C
230V,
1 phase
D
230V,
3 phase
E
400V,
3 phase
F
230V,
1 phase
901 RAIL, mounting
255028 255028 255028 255028 255028 255028 1
902 CLAMP, block, end
255045 255045 255045 255045 255045 255045 1
903 HOLDER, fuse terminal, block
255043 255043 255043 255043 255043 255043 2
904 FUSE
255023 255023 255023 255023 255023 255023 2
905 TERMINAL, block
255042 255042 255042 255042 255042 255042 4
906 TERMINAL, end cover
--- --- --- --- --- --- 1
907 BRIDGE, plug in, jumper
255044 255044 255044 255044 255044 255044 2
908 BLOCK, terminal ground
255046 255046 255046 255046 255046 255046 1
909 BREAKER, 1 pole, 50A
255026 255026 255026 255026 255026 255026 1
910 CONTACTOR, relay, 65A
255022 255022 255022 255022 255022 255022 1
911 BREAKER, 2 phase, 40A
247768 247768 247768 247768 247768 247768 1
912 BREAKER, 2 phase, 25A
255050 255050 255050 255050 255050 255050 2
BREAKER, 2 phase, 40A
247768 247768 247768 247768 247768 247768 2
913 BREAKER, 2 phase, 20A
255049 255049 255049 255049 255049 255049 1
914 CONNECTOR, power lug
117679 117679 3
CONNECTOR, power lug
117679 117679 2
915 BAR, power buss, 3 phase
117805 117805 1
BAR, power buss, 1 phase
117678 117678 1
916 CABLE, harness lower
247802 247802 247802 247802 247802 247802 1
917 CABLE, harness upper
247805 247806 247804 247805 247806 247804 1
918 CONNECTOR, 2 pin large
255027 255027 255027 255027 255027 255027 3
919 CONNECTOR, 3 pin
247522 247522 247522 247567 247567 247567 1
920 CONNECTOR, 4 pin
255031 255031 255031 255031 255031 255031 1
922 CABLE, harness
247791✓
17H075✿
247791✓
17H075✿
247791✓
17H075✿
247791 247791 247791 1
