11309637
1. Hold gun with nozzle straight up.
2. Turn locknut clockwise until you see and feel trigger
raise slightly.
3. Turn locknut 3/4 turn counterclockwise.
NOTE: When needle is properly adjusted,
trigger will move freely.
ADJUST NEEDLE
3/4 Turn
4. Connect fluid hose, install tip and guard.
5. Prime Sprayer, see sprayer manual.
6. Trigger gun into grounded metal bucket until fluid
flows from gun.
To Next Page
