10 309637
12. Grease o–rings of new needle using a
nonsilicon grease.
13. Grease threads of diffuser/seat. Place
gasket on diffuser/seat.
Grease
Gasket
14. Squeeze trigger while installing gasket and
diffuser/seat. Torque to 26–32 ft lb
(19–24 NSm).
26–32 ft–lb (19–24 N.m)
SILICON
