Shutdown and Cleanup
12 309585A
Removing Material Hopper from Sprayer
The material hopper can be removed for cleaning. To
remove material hopper:
1. Loosen bottom
fitting.
2. Lift material hop-
per straight up,
off unit.
3. Plug opening on
bottom of material
hopper with your
hand.
4. Take hopper to cleaning area.
To reassemble:
1. Place material hop-
per on sprayer,
aligning fitting to
sprayer.
2. Hand tighten fitting.
Touch-up Hopper Attachment
When you have finished spraying
1. Shut off compressor. Disconnect air line from gun.
2. Drain material into a
bucket until most of the
texture material is out of
hopper.
3. Fill hopper with clean
water. Remove nozzle
from gun and allow water
to flow through and out of
gun.
4. Flush until gun is clean
5. Turn power switch ON.
6. Open gun air valve.
7. Trigger gun to blow air through tip, clearing out any
remaining material.
8. Remove hopper from gun and finish cleaning all
components. A soft brush may be used to help
loosen any dried on material from surface.
To improve working condition for future use, after
cleaning, apply a few drops of light oil to:
• air hose quick disconnect
• material hose connections
• flow adjustment on gun
Transporting the Sprayer
The handle and hopper can be removed from the
sprayer for storage or transporting.
To remove hopper from sprayer, follow the procedure
described on page 12.
To remove the handle:
1. Loosen the two (2) wing-nut screws on either side of
the handle.
2. Squeeze the handle together.
3. Remove.
TI2465
TI2462
ti2560a
Be sure to keep air passages in needle clean and
free of material.
ti2559
