Repair
312497ZAB 11
Section 3: Purge Air from Pump to Master Divider Valve Lines
Refer to FIG. 9 when following this procedure.
1. Install the line from the system pump to the master
divider valve, but do not completely tighten the
connection at the master valve lube inlet.
2. Cycle the system pump until air-free lubricant flows
from the line at the master divider valve lube inlet.
3. Tighten the fitting at the lube inlet port while the
lubricant is still flowing.
The system is now ready for operation.
FIG. 9
TI11114
BLEED THROUGH
SECONDARY
MASTER
ALL PORTS
SYSTEM PUMP
LUBE POINT
