Warnings
6 313381L
QUICK START-UP GUIDE
SETUP
1
Remove spray tip and guard from gun.
2
Connect hose to gun and sprayer.
3
Turn Power Switch OFF. Plug sprayer into
grounded outlet.
FLUSHING
1
Turn Pressure Control Knob left (counterclock-
wise) to minimum pressure.
2
Turn Spray/Prime valve to PRIME.
3
Unclip small drain tube from large suction tube
and place into waste pail.
4
If spraying oil-based materials,* submerge
suction tube in paint thinner or compatible
oil-based cleaning solution.
If spraying water-based materials, submerge
suction tube in water.
5
Turn Power switch ON. With Spray/Prime
valve still at PRIME, turn Pressure Control
Knob to right (clockwise) until pump starts.
6
Allow fluid to flow out of prime tube, into waste
pail, for 30 to 60 seconds. turn power switch
OFF.
To Next Page
