Know Your Sprayer
10 3A3529C
ProLTS 170 Stand Model
U
A PushPrime™ Button
B Prime/Spray Valve
C Pressure Control Knob
D ON/OFF Switch
E Suction Tube
F Drain Tube (with diffuser)
G Airless Spray Gun
H Reversible Spray Tip
J Tip Guard
K Gun Trigger Lock
LGun Fitting
M Gun Filter (inside handle)
N ProXChange™ Pump (behind Easy
Access Door)
OInlet Valve
P Airless Hose Connection
Q Airless Hose
R InstaClean™ Filter (inside fluid outlet)
T Inlet Strainer
U Power Cord
V Easy Access Door
W Suction Tube Drip Cup
X Pump Removal Tool
YOutlet Valve
Z Inlet Valve Removal Tool
Model/Serial Tag (Not shown, located
on bottom of unit.)
See Quick Reference, page 31 for more
information.
