Wiring Diagram - 110/120V
50 3A3529C
Wiring Diagram - 110/120V
LTS 15/LTS 17:
ProLTS 170/ProLTS 190
GREEN
ON/OFF
SWITCH
WHITE
BLACK
PRESSURE SWITCH
WHITE
BLACK
MOTOR
ti14050a
ti27233a
M
