Technical Data
Model 100–120V,
∅, A, Hz
220–240V,
∅, A, Hz
Generator
Minimum
W
Motor
HP (W)
Cycles per
gallon (liter)
Maximum
Delivery
gpm (lpm)
Maximum
Tip size
Fluid
Outlet
npsm
1 gun 2 guns
695 1, 15,
50/60
1, 10,
50/60
3000 0.9 (373) 566 (150) 0.6 (2.3) 0.026 N/A 1/4 in.
795 1, 15,
50/60
1, 10,
50/60
4000 1.0 (466) 244 (64.6) 0.8 (3.0) 0.028 0.019 1/4 in
1095 1, 15/20,
50/60
1, 10,
50/60
4000 1.2 (560) 200 (53) 1.1 (3.8) 0.032 0.021 1/4 in
Basic Sprayer Wetted Parts: . . . . . . . . . . . . . . . . . . . . . . . . . . . .
zinc-plated carbon steel, polyurethane, polyethylene,
stainless steel, PTFE,
Delrin, chrome plating,
leather, V-Max UHMWPE, aluminum, stainless
steel, tungsten carbide
NOTE: Delrin
is a registered trademark of the
DuPont Co.
Dimensions
Model Style Weight lb (kg) Height in. (cm) Width in. (cm) Length in. (cm)
695 Hi–Boy 87 (39) 30 (76) 22.5 (57) 25.5 (65)
Lo–Boy 78 (35) 22 (56) 19.5 (49.5) 27 (69)
795 Hi–Boy 107 (48.5) 30 (76) 20.5 (52.1) 28 (71)
Lo–Boy 101 (46) 22 (56) 22.5 (57) 27 (69)
1095 Hi–Boy 120 (54) 30 (76) 22.5 (57) 29 (74)
Graco Phone Number
TO PLACE AN ORDER OR FOR SERVICE, contact your Graco distributor,
or call 1–800–690–2894 to identify the nearest distributor.
All written and visual data contained in this document reflects the latest product information available at the time of publication.
Graco reserves the right to make changes at any time without notice.
Sales Offices: Minneapolis, Detroit
International Offices: Belgium, Korea, Hong Kong, Japan
www.graco.com
PRINTED IN USA 309251 01/2001, Revised 3/2003
