Component Identification
18 312359J
User Interface Display
NOTE:
For details regarding the user interface display see User
Interface Display, page 61.
Main Display Screen Components
The following figure calls out the navigational, status, and general informational components of each display screen.
F
IG. 7: Main Display Screen Components (shown with all display features enabled)
NOTICE
To prevent damage to soft key buttons, do not press
the buttons with sharp objects such as pens, plastic
cards, or fingernails.
Current Date and Time
Navigate to screens
within same group
Go back one screen
Current Status Bar
Navigational Bar
Function Display
Remaining Potlife Time
To Next Page
