Graco XM Series Operation Manual

Models
312359J 7
Models
Check the identification plate (ID) for the 6-digit part number of the sprayer. Use the following matrix to define the
construction of the sprayer, based on the six digits. For example, Part XM1A00 represents an XM Plural-Component
sprayer (XM); 5200 psi pump set with pump filters (1); wall power supply, no heaters, no junction box, and is not
approved for hazardous areas (A); with no additional kits (00).
NOTE:
Some configurations in the following matrix cannot be built. Consult with distributor or Graco representative.
To order replacement parts, see Parts section the XM Plural-Component Sprayer Repair-Parts manual 313289. The
digits in the matrix do not correspond to the Ref. Nos. in the Parts drawings and lists.
Location Category Key:
NE Not for use in explosive atmospheres.
EH For use in explosive atmospheres and hazardous
locations
.
XM sprayers are not approved for use in hazardous
locations unless the base model, all accessories, all
kits, and all wiring meet local, state, and national
codes.
XM 1 A
00
First and
Second
Digits
Third Digit Fourth Digit
Fifth and
Sixth
Digits
System Choice
(See Table 1 for lower models) Kit Choice
Additional
Kit
Pump Set
(hose/gun)
Pump
Filters
Remote
Manifold
Control
Box
Fluid
Heaters
Junction
Box
Location
Category
Approvals
(see page 8
for approvals
)
See Table
2 for
selections
XM
(plural com-
ponent
sprayer
mounted
on a frame)
1 5200 psi
✔
A
Wall Power
Supply NE
CE, FM,
FMc
2 5200 psi B
Wall Power
Supply
✔✔
NE CE, FM,
FM
c
3 6300 psi
✔
C
Wall Power
Supply
✔
NE CE, FM,
FMc
4 6300 psi D
IS/
Alternator EH
CE, FM,
FMc, Ex
5 5200 psi
✔✔
E
IS/
Alternator
✔
EH
CE, FM,
FMc, Ex
6 5200 psi
✔
7 6300 psi
✔✔
8 6300 psi
✔
