Cleaning Filter
310743A
21
3.
Disconnect trigger guard f
rom gun body beneat
h dif-
fuser b
y pushing up on gua
rd hook and pulling
it out
of notch.
4.
The trigger guard benea
th the gun handle can the
n
be used as a wrench to loosen th
e nut.
***See
Impor
tant
note on page 9.***
TI5052A
TI5057A
TI5053A
TI5058A
Loosen
TI5060A
TI5055A
TI5054A
TI5059A
20
22
