Repair
24
310743A
Repair
Repair Kit 248837 is av
ailabl
e. P
ar
ts
included w
ith the kit are mar
ked with
*
.
Disassembl
y
F
ollow
Pressure Relief Pr
ocedure
, page 10.
W
A
RNING
Read wa
r
nings, pa
ge 3.
1.
Engage tr
igger lock.
2.
Disconnect fluid hose
. Remove
tip and tip guard (20)
.
3.
Using a wrench, remo
v
e the cap (4) with spring (5)
(releases spring tension on needle
).
TI5049A
20
TI5184A
5
4
T15185A
23
25
