Graco XTR 7 User Manual

XTR 7 Parts List
310743A 31
XTR 7 Parts List
Part Nos. 248609, 248611, 248612, 248613, 248614
* Parts included in Repair Kit 248837, purchased sep-
arately. Installation tool included.
▲ Replacement Danger and Warning labels, tags, and
cards are available at no cost.
Ref.
No. Part No. Description Qty.
1 15E178 BODY, gun 1
2* ---- SEAL, retainer assembly 1
3* ---- GASKET 1
4 15A864 CAP, end 1
5 117350 SPRING, compression 1
6 15E088 RETAINER, needle 1
7 15E085 PIN, actuator 2
8* ---- STEM, valve 1
9* 156766 GASKET 1
10* ---- SEAT, valve 1
11 ---- PIN, pivot (included with items 16a,
16b, 16c)
1
12 ---- SCREW, cap hex hd (included with
items 16a, 16b, 16c)
1
13 248952 HANDLE, tube assembly (includes
item 24)
1
14* 179733 SEAL, sleeve 1
15a 276997 HANDLE, gun (see table below) 1
15b 15E083 HANDLE, gun (see table below) 1
16a 287449 TRIGGER (see table below) 1
16b 287450 TRIGGER (see table below) 1
16c 287451 TRIGGER (see table below) 1
18 245994 RETAINER, RAC tip 1
19 GHDxxx SWITCH, tip 519 size included
(includes items 19a - 19d)
(see table below)
1
19a ---- SEAL, fluid 1
19b ---- GASKET 1
19c ---- TIP, spray hd RAC 1
19d ---- SCREW, mach pn h 1
24 15B958 O-RING, packing (included with
item 13)
1
26 287032 FILTER, 60 mesh (included with
gun)
1
287033 FILTER, 100 mesh
287034 FILTER, 60 and 100 mesh combo
29
▲ 222385 WARNING CARD 1
34
▲ 187346 WARNING TAG 1
Ref.
No. Part No. Description Qty.
Gun Part No.
Reference Nos.
15a 15b 16a 16b 16c 19
248609
✔✔
248611
✔✔✔
248612
✔✔✔
248613
✔✔ ✔
248614
✔✔✔
