Pressure Relief Procedure
10 310743A
Pressure Relief Procedure
WARNING
Read warnings, page 3.
1. Engage trigger lock.
TI5049A
2. Shut off pump.
3. Disengage trigger lock.
TI5048A
4. Hold a metal part of the gun firmly to a grounded metal pail.
Trigger gun to relieve pressure.
T12178A
