Pressure Relief Procedure
310743A
11
5.
Engage tr
igger lock.
TI5049A
6.
Open drain
va
lve
. Lea
ve
drain v
alve open.
TI5175A
7.
If pressure is not fully reliev
ed:
•
Spra
y tip is clogged
SwitchTip
:
F
ollow procedure on
page 16.
Flat Tip:
Slowly loosen tip guard retaining nut to
relie
v
e pressure. Remo
ve and clear tip
.
•
Hose is clogged
Slowly loosen ho
se end coupling to relie
ve pressure.
Clean hose obstruction.
10
12
Table of Contents
Table of Contents
2
Manual Conventions
3
System Requirements
6
Grounding
7
Gun Trigger Safety
8
Important
9
Pressure Relief Procedure
10
Operating Gun
12
Adjusting Spray Pattern
14
Maintenance
15
Flushing
18
Cleaning Filter
20
Repair
24
Disassembly
24
Assembly
27
XTR 7 Parts
30
XTR 7 Parts List
31
Part Nos. 248609, 248611, 248612, 248613, 248614
31
XTR 7 Parts List
32
Part No. 248610
32
Technical Data
33
Xtr 7
33
Graco Standard Warranty
34
Graco Phone Numbers
34
