Maintenance
16
310743A
If RA
C Spra
y Tip Clogs
1.
If spra
y tip clogs while spra
ying, stop spr
aying
immediately
.
WA
R
N
I
N
G
Read wa
r
nings, pa
ge 3.
2.
Engage tr
igger lock.
TI5049A
3.
Rotate (G)
180° (arr
ow points back).
TI
5181A
G
TI5181A
4.
Disengage trigger loc
k.
TI5049A
5.
T
o remove clog, trigge
r gun into a pail or onto the groun
d.
TI5046A
