Graef HA 800 - Technical Data and Options

Description
12
2.3 Technical data
HA 800 HA 810
Dimensions L x W x H 600 x 840 x 450 mm 600 x 840 x 500
Workspace L x W x H 700 x 900 x 640 mm
Minimum: 480 x 440 mm Space occupied L x W
Ideal: 540 x 440 mm
Weight W approx. 56 kg
Blade diameter D 300 mm
Blade speed N 229 rpm
Max. 250 x 180 mm Dimensions with chain frame L x H
Min. 30 x 30 mm
Dimensions without chain frame L x H Max. 260 x 195 mm
Carriage length L 300 mm
Largest distance between last slice
clamp and blade (clamping
distance)
L 150 mm 155 mm
Tray size L x W 300 x 255
Length of tray run T 160 mm
Slice thickness T 0.5 - 10 mm
Slicing speed maximum V Max. 160 strokes per minute
Noise level acc. To EN ISO 11204,
at idling
Leq < 69 dB (A)
Vibration total value < 2,5 m/s²
Power consumption P
1
[W]
Frequency f [Hz]
Current I [A]
Voltage U
N
[V]
See type plate
